·高精度,高解析度

·搭配通信介面之数位电表

·两组不同变数,同时显示

·RS-232C介传送电脑资料(3801-01含软件体)

·AC+DC,dBm,温度测量,派衡信号输出负载测量(3801)

日本日置HIOKI 3801-50数字万用表的技术指标

日本日置HIOKI 3801-50数字万用表的订货信息

·3852RS-232C介面组合

·9018至9183温度感知器

·9014高电压测试线

·9472至9476温度感知器

日本日置HIOKI 3801-50数字万用表的附件

·3801:3851测试线(1)脚架(1)

·3801-01:3851测试线(1)脚架(1)

·3852RS-232C组合

High Performance, Superior Functionality, and Advanced Safety

• CAT IV 600V with built-in protective circuitry for all functions
• True RMS and Super High ±0.025% accuracy (when measuring DC voltage)
• Large 51000 maximum count display
• Optional PC application package for transferring important measurement data and basic remote control

Basic specifications

AC measurement

True RMS value measurement system

Display

Data display	Primary display and secondary display: 4 1⁄2 characters
Maximum count	[51000], [15000] 1000 mV/V range, [99999] Hz function, [9999] C function
Bar graph	Scale display, 21 dot bar display. +/- polarity indication

Measurement function/basic accuracy

DC voltage	51.000mV to 1000.0V
Basic accuracy	±0.025%rdg.±5dgt.
AC voltage	51.000mV to 1000.0V
Basic accuracy	±0.4%rdg.±25dgt.
AC+DC voltage	51.000mV to 1000.0V
Basic accuracy	±0.4%rdg.±30dgt.
DC current	510.00μA to 10.000A
Basic accuracy	±0.15%rdg.±25dgt
AC current	510.00μA to 10.000A
Basic accuracy	±0.7%rdg.±20dgt.
AC+DC current	510.00μA to 10.000A
Basic accuracy	±0.8%rdg.±25dgt.
Resistance	510.00Ω to 510.00MΩ, 510.00nS
Basic accuracy	±0.05%rdg.±5dgt
Continuity	Buzzer sounds for less than 1000 count in each range
Diode	Measured current: 1.00mA, open terminal voltage: 4.8V
C (capacitance)	9.999nF to 99.99mF
Basic accuracy	±1.5%rdg.±5dgt
Frequency	99.999Hz to 999.99kHz
Frequency counter	99.999Hz to 99.999MHz
Basic accuracy	±0.02%rdg.±3dgt. (less than 20MHz)
Temperature (k)	−200.0 to 1372.0°C
Temperature (J)	−210.0 to 1200.0°C
Duty ratio	99.99%
Pulse width	510.00ms to 1999.9ms
Pulse output	0.5 to 4800Hz, 2.8V

Additional Functions/General Specifications

Additional functions	Autorange / Manual range / PC-compatibility (RS232C, USB) / Refresh hold / Trigger hold / Peak hold / Recording /4 – 20mA (0 – 20mA)% conversion display /dB decibel conversion display / Relative value (REL) display/ Terminal A improper connection warning / Display backlight / Auto power save / Battery life warning / Overload warning
Sample rate	3.75 times/s (V and, A measurement), 1.65 times/s (AC + DC measurement), 1.12 times/s (Hz and DUTY ratio measurement; [1Hz or more], pulse width measurement [1Hz or more]) , 7.5 times/s (Ωmeasurement)
Max. input voltage	V terminal ... DC 1000V/AC 1000Vrms (sin) or 107V Hz
Max. input current	A terminal ...Continuous to DC/AC 10A; up to DC/AC 20A within 30s μA ,mA terminal ... DC/AC 510mA
Location / Temp. and humidity range for use	Indoors, up to an altitude of 2000m/ 0°C to 50°C /up to 80%rh (no condensation)
Power supply (operating time)	6F22(006P, 9V Manganese) battery) ×1 (20 hours) or 6LR61(9V Alkaline) battery ×1 (50 hours)
Dimensions and mass	90mm (3.54") W×192mm (7.56") H×37mm (1.46") D mm (excluding protrusions) 100mm (3.94") W×202mm (7.95") H×57mm (2.24") Dmm (including holster) /450g (15.9oz) (with battery) 680g (24.0oz) (with holster and battery)
Applicable standards	Safety: EN61010-1:2001 EN61010-031:2002 Pollution class 2 Measurement category CAT III 1000V, CAT IV 600V Expected overvoltage 8000V EMC: EN61326:1997 + A1: 1998 + A2:2001
Warranty period	3 years (excludes measurement accuracy)
Accessories	Test Lead 3851-10 , holster (for main unit),battery (6LR61) × 1 (for monitor in main unit)
